Unlimited New View (UNV)

UNV,UAC-P112-AF40-W (PT) (Dolphin Series)2MP high quality imaging

LE 0 EGP
This is Estimated Price, Discount Final Price After Confirmation Call

Estimate delivery times: 3-6 days

Return within 14 days of purchase. Duties & taxes are non-refundable.

  • Part Number: UAC-P112-AF40-W
  • Available: instock
UNV,UAC-P112-AF40-W (PT) (Dolphin Series)2MP high quality imaging
Unlimited New View (UNV)
UNV,UAC-P112-AF40-W (PT) (Dolphin Series)2MP high quality imaging
LE 0 EGP

• 2MP high quality imaging
• 4mm Lens , 30m IR Illumination distance
• TVI/AHD/CVI/CVBS
• Supports white light illumination, 24/7 color images
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP66 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
• Supports 0 to 345° pan range, 0 to 90° tilt range
• Supports digital defog

UAC-P112-AF40-W
Sensor
Pixel 2 MP
Sensor Size 1/2.9" CMOS
Min. Illumination 0.005 lux (F1.6, AGC ON)
0 lux (white light on)
Lens
Focus 4.0 mm
Lens Mount M12
Angle of View (H) 83.8°
Angle of View (V) 42.7°
Angle of View (D) 100.1°
Illuminator
Illuminator Number Eight white-light illuminators
Illumination Distance 30m
Lifetime ≥ 20000 hours
Video
Resolution 1080P: 1920(H)×1080(V)
720P: 1280(H) ×720(V)
Frame Rate TVI: 1080P@25fps (default), 1080P@30fps; 720P@25fps, 720P@30fps
AHD: 1080P@25fps, 1080P@30fps; 720P@25fps, 720P@30fps
CVI: 1080P@25fps, 1080P@30fps; 720P@25fps, 720P@30fps
CVBS: PAL, NTSC
Shutter Time PAL: 1/25s-1/50000s，
NTSC: 1/30s-1/50000s
Exposure Mode Four modes: Global (default), BLC, HLC, DWDR
Day/Night 24/7 color images
Digital Noise Reduction 2D/3D
White Balance Two modes: Auto (default), Manual
WDR DWDR
Flip Supports 180°horizontal flip, 180°vertical flip
Digital Defog Support
PTZ
Pan Range 0° to 345°
Pan Speed 1° to 40°/s
Tilt Range 0° to 90°
Tilt Speed 1° to 30°/s
Number of Presets 32
Control Mode 485/BNC
Patrol N/A
Baud Rate 9600 bps/4800 bps/2400 bps/1200 bps
Interface
Power Interface 5.5 mm Power Interface
Video Output BNC, supports TVI/AHD/CVI/CVBS
RS485 Support
Operating Environment
Temperature -30 ℃ to 60 ℃ (-22 ℉ to 140 ℉)
Humidity ≤ 95% RH (non-condensing)
Surge Protection 4 KV for power, 4 KV for video output interfaces, 6 kV for RS485 interface
Ingress Protection IP66
General
Power DC 12 V ± 25%
Power Consumption MAX 8.5W
Mount Wall Mount, Pendant Mount
Dimensions Φ118mm*190mm (diameter*height)
Material Graphene + Plastic
Weight 477g(1.05lb)
