| Installation Type |
|
| Dimensions without packaging (H x W x D) [mm(in.)] |
Diameter x depth: 180 mm x 35 mm (7.09 in. x 1.38 in.) |
| Dimensions with packaging (H x W x D) [mm(in.)] |
200 mm x 231 mm x 52 mm (7.87 in. x 9.09 in. x 2.05 in.) |
| Weight without packaging [kg(lb)] |
0.46 kg (1.01 lb) |
| Weight with packaging [kg(lb)] |
0.80 kg (1.76 lb) |
| Storage |
NAND Flash 256 MB |
| Console port |
None |
| Maximum power consumption [W] |
11.2 W |
| Power supply mode |
|
| Rated input voltage [V] |
12 V |
| Input voltage range [V] |
DC: 12 V ± 10%
PoE: 802.3af
|
| Service port surge protection |
PoE port:
Common mode (8 wires to ground): 4 kV (1.2/50 us, 42 ohms), criterion C
|
| Maximum number of physical ports on the entire device |
GE (RJ45) x 1, 10M/100M/1000M auto-sensing |
| Long-term operating temperature [°C(°F)] |
–10°C to +50°C (14°F to 122°F) (From 1800 m to 5000 m [5905.51 ft. to 16404.20 ft.], the maximum temperature of the device decreases by 1°C [1.8°F] for every 300 m [984.25 ft.] increase in altitude.) |
| Storage temperature [°C(°F)] |
–40°C to +70°C (–40°F to +158°F) |
| Long-term operating relative humidity [RH] |
5% RH to 95% RH, non-condensing |
| Long-term operating altitude [m(ft.)] |
–60 m to +5000 m (–196.85 ft to +16404.20 ft) |
| Atmospheric pressure [kPa] |
53kPa - 106kPa ETSI 300 019-2-3 |
| Ground |
floating ground |
| BLE |
Not supported |
| Radio number |
2 |
| Operating frequency band |
|
| MIMO spatial streams |
Radio 0 (2.4 GHz): 2x2
Radio 1 (5 GHz): 2x2
|
| Wi-Fi standard |
2.4 GHz: 802.11b/g/n/ax
5 GHz: 802.11a/n/ac/ac Wave 2/ax
|
| Radio interface |
Built-in smart antennas |
| Antenna gain |
2.4G:
4 dBi/chain (peak)
2 dBi (combined gain)
5G:
5 dBi/chain (peak value)
3 dBi (combined gain)
|
| Maximum transmit power |
2.4G:
20 dBm/chain
23 dBm (combined power)
5G:
20 dBm/chain
23 dBm (combined power)
|
| Singal radio transmit power [dBm] |
2.4G: -10 dBm to 20 dBm/chain
5G: -10 dBm to 20 dBm/chain
|
| MTBF [year] |
205.07 year |
| MTTR [hour] |
0.5 hour |
| Frequency stability [ppm] |
+/-20 |
| 802.3bt power supply description |
No function is limited. |
| 802.3at power supply description |
No function is limited. |
| 802.3af power supply description |
No function is limited. |
| DC power supply description |
No function is limited. |
