Floor-Standing Cabling Rack 42U W800D800 Fixed 19" Glazed Door R7035

This product is a floor standing enclosure designed for circulation applications with switches and routers. The enclosure dimensions are 42U, 800mm width and 800mm depth. The top and bottom frames are mechanically assembled by Torx screws to the vertical structure uprights, thus forming a rigid framework. Glazed reversible front door, 4 mm Securit glass, opening to 180°, 1-point lock with a key no. 333. Top and bottom side knock-out areas for cable entry and a large opening on the bottom and knock-out area on the rear for cable entry.

Main
Range Actassi
product name Actassi VDA
Product or component type 19" enclosure
Device application Cabling
applications To protect network connectivity equipment
To mount 19" equipment
Enclosure type Network Cabinet
support equipment 2 x 19" uprights recessed of 120 mm from the front (pitch 25 mm)
front face Glazed door
Door type Front glazed door - with 1 point locking system (key: 333) - reversible opening at 180 °
Accessibility for operation Side
Front
Top
Rear
Removable parts Front door removable toolless
Top blanking plate
Bottom blanking plate
Side panels removable toolless
Rear panel removable toolless
colour Door: light grey (RAL 7035)
Panels: light grey (RAL 7035)
Top and bottom: light grey (RAL 7035)
Structure: dark grey (RAL 7011)
Complementary
Device composition 1 x glazed door front
2 x panels side
2 x 19" uprights front
1 x assembled structure CBLX torx
1 x roof with removable blanking plate top
1 x panel rear
4 x levelling feets
load rating 400 kg static
250 kg dynamic
back face Panel
side face Panel
Number of cut-out 1 cut-outbottom
1 cut-outtop side panel
1 cut-outtop - split in 3 parts
installation mode Floor-standing
Material Sheet steel: structure
Sheet steel: door
Sekurit glass: door
Galvanized steel: upright
Sheet steel: panel
Surface finish Epoxy-polyester powder
Width 800 mm
Height 2000 mm
Depth 800 mm
Product weight 108 kg
Number of rack unit 42U
targeted region Europe
Environment
IK degree of protection IK08 conforming to IEC 62262
IP degree of protection IP20 conforming to IEC 60529
Standards IEC 60297-3-100
EIA-310D
Packing Units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 213.0 cm
Package 1 Width 84.0 cm
Package 1 Length 85.0 cm
Package 1 Weight 108.0 kg
Contractual warranty
Warranty 18 months
